Product Description：
| Name : | Electric Actuator | |
| Model : | 05-200 | |
| Output Torque : | 50Nm-2000Nm | |
| Suitable Size for Butterfly Valve : | DN40-DN400 | |
| Working temperature : | -10℃～60℃ | |
| Protection Level : | IP67 | |
| Shell Material : | Aluminium Alloy | |
| Application : | Municipal construction, electric power, pharmaceutical, petrochemical and so on | |
Product Advantages:
A. Multiple Functions and Types
1. Intelligent type, proportional type, switching type, all kinds of signal output.
2. Several action times for choice, such as 5 seconds, 10 seconds, 15 seconds, 30 seconds, 60 seconds.
3. The intelligent control module is integrated into the body of the electric actuator without an external positioner.
B. Reliable Performance
1. The worm gear is forged by special copper alloy with high strength, good wear resistance and high transmission precision.
2.Key parts such as bearings and electrical components are imported famous brand products to improve their service life.
3.Through 1500V withstand voltage test, F grade insulated motor is safe and reliable.
4.IP67 high standard protection class.
C. Beautiful Appearance and easy to operate
1. Beautiful and smooth aluminium shell.
2. No refueling, no spot inspection, waterproof and anti-rust, installation at any angle.
3.The external connection is simple and has a variety of voltage models to choose.
